TAI 906-A – HORIZONTAL CYLINDRICAL HIGH PRESSURE AUTOCLAVE S.S LINING
TECHNICAL SPECIFICATIONS
| TECHNICAL SPECIFICATIONS |
DETAILS |
| GASKET |
Made of joint less silicon rubber |
| EXHAUST PRESSURE |
Manually through the exhaust valve, sterilizing pressure: 1.2 to 2.5 kgf/cm2 (15 to 35 Psi) at 121°C to 134°C |
| WORKING PRESSURE |
From 15 psi to 35 psi |
| PRESSURE GAUGE |
0.2:1 kgf/cm2 (60 psi) |
| TUBULAR STAND |
Mild Steel |
| SUPPORTING RING |
SS 304 Grade Stainless Steel |
| PRESSURE GAUGE |
SS 304 Grade stainless steel |
| EXTERNAL WALL |
SS 304 Grade Stainless steel |
| TOP LID |
SS 304 Grade Stainless steel |
| TRAY |
SS 304 Grade Stainless steel |
DIMENSION / CAPACITY
| DIMENSION INCH |
DIMENSION (MM) |
CAPACITY |
LOAD |
| 16X24 |
400X600 |
78 Liter |
6 KW |
| 16X36 |
400X900 |
115 Liter |
6 KW |
| 16X48 |
400X1200 |
160 Liter |
9 KW |
| 20X36 |
500X900 |
175 Liter |
9 KW |
| 20X48 |
500X1200 |
235 Liter |
9 KW |
| 22X48 |
550X1200 |
300 Liter |
12 KW |
| 24X48 |
600X1200 |
350 Liter |
12 KW |
